The PMD1100A is a 1100mm length extension unit, which is suitable for the use on the floor tom side of the kit. It includes a J30TS joint bracket, which allows you to attach this unit to another vertical post.
-1100mm Curved Pipe x 1pc -850mm Straight Pipe w/19.1mm diameter Joint x 1pc -40mm x 20mm x 450mm Square Pipe x 1pc -Leg Joint Bracket x 1pc -Rubber Foot x 2pc -Cross Joint Bracket (J30TS) x 2pc -Multi Holder (J34T) x 1pc -Memory Lock (A13S) x 3pc
SPECIFICATIONS
Learn More
Product specification information is listed below.
Learn More
FEATURES
Learn More
The following is a detailed introduction to the many unique mechanisms on board.
PMD1100A DescriptionLearn More
1100mm Curved Pipe (φ38.1) x 1pc 850mm Straight pipe w/φ19.1mm Joint (φ38.1) x 1pc 40mm x 20mm x 450mm Square pipe x 1pc Leg Joint Bracket x 2pc Rubber foot x 2pc Cross Joint Bracket (J30TS) x 2pc Pipe Holder (J34T) x 1pc Memory Lock (A13S) x 3pc
Close
Horizonal Pipe Guide LineLearn More
Use this center mark on horizontal pipes to line up J30TS clamps. This will ensure that the angle of all toms and cymbals mounted on the horizontal pipe are consistent.
Close
Vertical Pipe Guide LineLearn More
Curved markings on vertical pipes, every 50mm, allow for easy and precise positioning of horizontal pipes.
Close
Learn More
VIDEOS
Learn More
A video summarizing the various features is available.
